E.7 BIOS SETUP
E.7.1 HOW to BEGIN THE ‘BIOS SET-UP’
How to begin the BIOS set-up is as follows,
1. Finish working and store the data.
2. Turn off and connect a full-keyboard, and turn on again.
3. BIOS set-up will run with pressing “F2” key while “Press <F2> to enter SETUP”
is displayed.
4. Menu screen is displayed. Change parameters if it is necessary.
About how to end, refer to the section 5. BIOS SETUP in MAINTENANCE.
