DIGITAL SERVO ADAPTER Connection manual Page 127

Connection manual
B–63463EN/01
D. OPTICAL CABLE
APPENDIX
119
Table D (a) Standard cable length
Internal cord type cable
External cable
A66L–6001–0023# A66L–6001–0026#LjRjjj
LjRjjj FANUC
Specification
Length LjRjjj Length
L150R0 A02B–0236–K851 0.15m L1R003 1.0m
L300R0 A02B–0236–K852 0.3m L3R003 3.0m
L1R003 A02B–0236–K853 1.0m L5R003 5.0m
L2R003 A02B–0236–K854 2.0m L7R003 7.0m
L5R003 A02B–0236–K855 5.0m L10R03 10.0m
L10R03 A02B–0236–K856 10.0m L15R03 15.0m
L20R03 20.0m
L30R03 30.0m
L50R03 50.0m
2. Cable selection
D Always use an external cable when the cable is to be laid outside
the power magnetics cabinet or main unit cabinet, where it may be
pulled, rubbed, or stepped on.
D Use an external cable when part of the cabling is to be subject to
movement. For example, when connecting a portable operation
pendant box to the power magnetics cabinet, the use of an external
cable is desirable because the cable is likely to be bent, pulled, or
twisted repeatedly even though frequent system operation is not
expected. However, the force likely to be applied when the cable
is installed or moved for maintenance purposes does not need to be
taken into consideration.
D Use an external cable in locations where sparks or flame are a
danger. Although the internal cord type cable is covered by
nonflammable resin, the cover, if exposed to frame for a long time,
may melt, allowing the fiber cable inside to burn.
D Use an external cable when the cable is expected to be pulled with
considerable force during installation (the force applied to the cable
must be within the specified tensile strength limit at all times). For
example, even though installing a cable in a cable duct can be
regarded as internal cabling, a cable of the appropriate type must
be selected according to the tensile force to be applied to the cable
during installation.
D Both the internal cord type and external cables have the same oil
and heat resistance properties.
