DIGITAL SERVO ADAPTER Connection manual Page 9

Connection manual
B–63463EN/01
1. PREFACE
1
1
PREFACE
This manual describes the electrical and structural specifications required
for connecting the Digital Servo Adapter to a machine.
This manual covers the range shown in the configuration diagram in
Chapter 2.
The devices should be connected and installed according to this
connection manual.
The table below lists manuals related to Digital Servo Adapter.
In the table, this manual is marked with an asterisk(*).
Table 1 Manuals Related to Digital Servo Adapter
Manual name
Specification
Number
CONNECTION MANUAL B–63463EN
*
OPERATOR’S MANUAL B–63464EN
MAINTENANCE MANUAL B–63465EN
PARAMETER MANUAL B–63470EN
FANUC AC SERVO MOTOR α series DESCRIPTIONS B–65142E
FANUC SERVO AMPLIFIER α series B–65162E
FANUC SERVO MOTOR β series DESCRIPTIONS B–65232EN
FANUC SERVO MOTOR β series
MAINTENANCE MANUAL
B–65235EN
