Power Mate i-Model D/H Descriptions Page 264

Descriptions

Page of 324

/ 324

TITLE

B-63173EN-1/02

EDIT

DATE DESIG. DESCRIPTION

FANUC

ower

ate i-

Look-ahead feed-forward control

Connection manual (function)

DRAW.NO. CUST.

SHEET

990624 New design

7.1.7

Look-ahead feed-forward control

General This function is designed for high-speed precise axis motion. With this function, the

delay due to acceleration/deceleration and the delay in the servo system which

increase as the feedrate becomes higher can be suppressed.

The tool can then follow specified values accurately and the errors of tool path can

be reduced.

This function becomes effective when look-ahead feed-forward control mode is

entered by G08P1 command.

・Available function In look-ahead feed-forward control mode, the "linear acceleration/deceleration

before interpolation for cutting feed" becomes automatically effective. For details on

the function, see another section.

Signal

look-ahead

feed-forward control

mode signal

G08MD<F066#0>

[Classification] Output signal

[Function] Informs it is in the look-ahead feed-forward control mode

[Output condition] The signal is "1" in the following case:

・It is in the look-ahead feed-forward control mode.

The signal is "0" in the following case:

・It is not in the look-ahead feed-forward control mode.

Signal address

#7 #6 #5 #4 #3 #2 #1 #0

F066 G08MD

Contents Summary of Power Mate i-Model D/H Descriptions
