Power Mate i-Model D/H Descriptions Page 68

Descriptions

Page of 324

/ 324

7. COORDINATE VALUE AND

DIMENSION

B–63172EN/01

NC FUNCTION

Conversion of inch and metric input can be commanded by the G code

command.

G20 : Inch input

G21 : Metric input

Whether the output is in inch system or metric system is parameter–set

when the machine is installed.

Command G20, G21 at the head of the program.

Inch/metric conversation can also be done by MDI setting.

The contents of setting data differs depending on whether G20 or G21 is

commanded.

WARNING

Never specify G20 or G21 for switching in the middle of a

program.

Numerals can be input with decimal points. Decimal points can be used

basically in numerals with units of distance, speed, and time. The position

of the decimal point is at the mm, inch, deg position.

There are two types of decimal point notation: calculator–type notation

and standard notation.

When calculator–type decimal notation is used, a value without decimal

point is considered to be specified in millimeters, inch or deg. When

standard decimal notation is used, such a value is considered to be

specified in least input increments.

Use parameters to select input method; whether to input by pocket

calculator type input, or by the usual decimal point input.

Values can be specified both with and without decimal point in a single

program.

Program command

Pocket calculator type

decimal point

programming

Usual decimal point

programming

X1000

Command value without

decimal point

1000mm

Unit : mm

1mm

Unit : Least input

increment (0.001 mm)

X1000.0

Command value with

decimal point

1000mm

Unit : mm

1000mm

Unit : mm

7.2

INCH/METRIC

CONVERSION

(G20, G21)

7.3

DECIMAL POINT

INPUT/POCKET

CALCULATOR TYPE

DECIMAL POINT

INPUT
