B-63173EN/02-12

3/4EDIT

DATE DESIG. DESCRIPTION

FANUC Power Mate – i MODEL D/ H

CONNECTION MANUAL

THE FUNCTION OF INCREMENT SYSTEM IS-C

TITLE

DRAW.NO. CUST.

SHEET

000530 New design

When bit 3(F10)of parameter No.8002 is set to 0

Data unit

IS-A,IS-B IS-C

Unit

Metric machine 1 0.1 mm/minLinear

axis

Inch machine 0.01 0.01 inch/min

Rotation axis 1 0.1 deg/min

When bit 3(F10)of parameter No.8002 is set to 1

Data unit

IS-A,IS-B IS-C

Unit

Metric machine 10 1 mm/minLinear

axis

Inch machine 0.1 0.01 inch/min

Rotation axis 10 1 deg/min

1 to 65535

(Actual values must fall within the ranges given in the following table.)

Data range

IS-A,IS-B IS-C

Unit

Metric machine 1～

～～

～100000 0.1～

～～

～12000.0 mm/minLinear

axis

Inch machine 0.01～

～～

～4000.00 0.001～

～～

～480.000 inch/min

Rotation axis 1～

～～

～100000 0.1～

～～

～12000.0 deg/min

1 to 65535

(Actual values must fall within the ranges given in the following table.)

Data range

IS-A,IS-B IS-C

Unit

Metric machine 0.01～

～～

～500.00 mm/revLinear

axis

Inch machine 0.0001～

～～

～9.9999 inch/rev

Rotation axis 0.01～

～～

～500.00 deg/rev

Replace the description of the table of " (7) Skip-feed per minute" of the " 3 axis control

feedrate signals EIF0g to EIF15g"

in the chapter " 15 PMC CONTROL FUNCTION" as

follows.

[ Unit of data ]

[Valid data range]

Replace the description of the table of " (8) Cutting feed - feed per rotation" of the " 3 axis

control feedrate signals EIF0g to EIF15g"

in the chapter " 15 PMC CONTROL FUNCTION"

as follows.

[Valid data range]
