16i/160i-LB Maintenance manual Page 151

Maintenance manual

Page of 512

/ 512

B–63665EN/01

3. INPUT AND OUTPUT OF DATA

131

14.In FILE No item, specify a file name. In this example input as follows:

@ P

INPUT

15.Press soft key [EXEC]. Then PMC parameters are started to be output.

16.After the PMC parameters have been output, set PARAMETER

WRITE to 0.

17.Press

RESET

to release alarm 100.

1. Select EDIT mode.

2. Press

SYSTEM

key several times, press soft key [PARAM], and

[PITCH] to select the SETTING screen for pitch error amount.

3. Press soft key [(OPRT)] and

4. Press soft key [PUNCH] and [EXEC], then pitch error compensation

amount is started to be output.

When custom macro function is equipped, values of variable no. 500 and

later are output.

1. Press

OFFSET

SETTING

key.

2. Press

key and soft key [MACRO] to select custom macro

variable screen.

3. Press soft key [(OPRT)] and then key

4. Press soft key [PUNCH] and [EXEC], then custom macro variable

values are output.

1. Select EDIT mode.

2. Press

OFFSET

SETTING

key and soft key [OFFSET] to display the tool

compensation amount screen.

3. Press [(OPRT)] key and soft key

4. Press soft key [PUNCH] an [EXEC] key, and the tool compensation

amount is started to be output.

3.2.4

Outputting Pitch Error

Compensation Amount

3.2.5

Outputting Custom

Macro Variable Values

3.2.6

Outputting Tool

Compensation Amount
