1. DISPLAY AND OPERATION
57
306 Machine coordinates of a slant axis in the Cartesian coordinate system
DGN
307 Machine coordinates of an orthogonal axis in the Cartesian coordinate system
DGN
[Data type] Two–word
[Unit of data]
Increment system IS–A IS–B IS–C Unit
Metric input 0.01 0.01 0.01 mm
Inch input
0.001 0.001 0.001 inch
Rotation axis
0.01 0.01 0.01 deg
[Valid data range] –99999999 to 99999999
These parameters are updated only when bit 0 (AAC) of parameter No.
8200 is set to 1, and any of the parameters below is set to 1:
D Bit 0 (AOT) of parameter No. 8201
D Bit 1 (AO2) of parameter No. 8201
D Bit 2 (AO3) of parameter No. 8201
D Bit 3 (QSA) of parameter No. 5009 (T series only)
D The interference check option is selected.
#7
310
#6
DTH
#5
ALP
#4
NOF
#3
BZ2
#2
BZ1
#1
PR2
#0
PR1
DGN
#0(PR1): The setting of the following parameters has been changed: Parameters
1821, 1850, 1860, 1861.
#1(PR2): The setting of the ATS bit (bit 1 of parameter 8302) has been changed.
#2(BZ1): The detected APC battery voltage is 0 V (Inductosyn).
#3(BZ2): The detected APC battery voltage is 0 V (separate position detector).
#4(NOF): The Inductosyn output no offset data.
#5(ALP): Before the α pulse coder detects a full single rotation, reference position
establishment by parameters was attempted.
#6(DTH): A controlled axis detach signal/parameter was input.
D Machine coordinates of
angular axis/orthogonal
axis
D Cause of the APZ bit (bit
4 of parameter 1815)
brought to 0
