5. DIGITAL SERVO

B–63665EN/01

216

D MAINTENANCE NO. (engineering change number for an amplifier

connected to each axis)

On an FSSB setting screen (other than the amplifier maintenance screen),

pressing soft key [(OPRT)] displays the following soft keys:

SET INPUTREAD

To enter data, place the machine in MDI mode or the emergency stop state,

position the cursor to the point where a desired item is to be input, then

enter the desired data and press soft key [INPUT] (or the

INPUT

key on the

MDI panel).

When soft key [SET] is pressed after data has been entered, a warning

message is displayed if the entered data contains an error. When the data

is satisfactory, the corresponding parameter is set up.

To restore the previous value of a parameter if, for example, an entered

value is incorrect, press soft key [READ].

When the power is turned on, values are read from the parameters and

displayed on the screen.

CAUTION

1 For the parameters to be specified on the FSSB setting

screen, do not attempt to enter values on the parameter

screen using the MDI or a G10 command. Use only the

FSSB screen to enter values for these parameters.

2 If pressing soft key [SET] results in a warning message

being displayed, retry data entry, or press soft key [READ]

to clear the warning message. Note that pressing the reset

key does not clear the warning message.

1) Amplifier setting screen

AMPLIFIER SETTING O1000 N00001

NO. AMP SERIES UNIT CUR. AXIS NAME

1A1–L α SVM–HV 40AL 1 X

2A1–M α SVM 12A 2 Y

3A2–L β SVM 40A 3 Z

4A3–L α SVM 20A 4 A

5A3–M α SVM 40A 5 B

7A4–L α SVU 240A 6 C

NO. EXTRA TYPE PCB ID

6 M1 A 0000 DETECTOR(8AXES)

8 M2 B 12AB

MDI **** *** *** 13:11:56

[SETTING][ ][ READ ][ ][ INPUT ]

D Setting
