11 Parameter setting
1. At emergency stop, turn on the power of CNC.
2. Follow the procedure below to set parameters concerned with FSSB.
In the case of using an analog servo interface unit, the FSSB automatic setting function is not
available. It is necessary to set the value of No.1023, No.1815, No.1905, No.14340 to14459, No.1936
to 1937 in the manual setting No.2 mode. Refer to “FSSB setting” of the connection manual (function
edition) about the detail of the setting.
When this parameter is set, the analog servo interface unit is basically treated in the similar way to
the separate type detector interface unit. (After this, the analog servo interface unit and the separate
type detector interface unit are called “an interface unit”.)
Follow the explanation below and the parameter manual of CNC and set the appropriate value.
Setting of servo axis number
No.
1023 Number of the servo axis for each axis
Data type: Byte
Valid data range: 1,2,3,…controllable axis number
Set the servo axis number for each axis.
Refer to the “FSSB setting” of connecting manual (function edition).
Setting of the position detector
No. 7 6 5 4 3 2 1 0
1815
A
PC
A
PZ OPT
APC 0 : Position detector is other than absolute pulse coder
1 : Position detector is absolute pulse coder
APZ Zero position of absolute pulse coder is:
0 : Not established
1 : Established
FSSB manual setting
No. 7 6 5 4 3 2 1 0
1902 FMD
Data type : Bit
FMD The setting mode of FSSB is
0 : Automatic.
1 : Manual setting 2.
Notice
In the case of using the analog servo interface unit, be sure to set 1.
