Series 30i/300i/300is/31i/310i/310is/32i/320i/320is-Model A Additional Manual Page 27

Additional Manual
26 30
EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
/
DESCRIPTIONDESIG.DATE
A
-65551EN/01
No.
14444 ATR value corresponding to connector 1 on the 1st interface unit
connected to the third FSSB line on additional axis board.
to
14451 ATR value corresponding to connector 8 on the 1st interface unit
connected to the third FSSB line on additional axis board.
Data type: Byte
Data range : 0 to 32
No.
14452 ATR value corresponding to connector 1 on the 2nd interface unit
connected to the third FSSB line on
additional
axis bo
ard.
to
14459 ATR value corresponding to connector 8 on the 2nd interface unit
connected to the third FSSB line on additional axis board.
Data type: Byte
Data range : 0 to 32
Each of these parameters sets the value(ATR value) of the address translation table
corresponding to each connector on a interface unit.
In each of these parameters, set a value obtained by subtracting 25 from the setting of
parameter No.1023 for the axis connected to a connector on an interface unit.
When there is an axis for which bit 6 or 7 of parameter No.1905 is set to use an interface unit,
set 32 for those connectors that are not used.
3. Turning off/on the power to CNC
The description of setting continues to 4. Servo initial setting.
