5.2.4 CABLE J37
Cable J37 is for between analog servo interface unit (JA4L) and the battery for separate
detector.
NOTE
If the cable is connected to JA4L when the separate absolute pulse coder battery case
contains the battery, the battery voltage is applied to the battery power supply pin (+6 V) for
each of the feedback connectors (JF101L to JF104L). In this case, if the battery line and 0 V
are short-circuited, the battery may heat up or the protection circuit within the analog servo
interface unit may fail. First, make sure the battery case contains no battery or the cable is not
connected to JA4L. Then, complete all cabling work and confirm cables are correctly
connected. Finally, place the battery or connect the cable to JA4L.
(
M3 terminal)
+
−
+6V 0V
JA4L
(PCR-EV20MDT)
1
11
2
12
3 0V 13
4
14
5
15
6
16
7 +6V 17
8
18
9
19
10
20
Battery for separate detector
A
nalog servo interface unit(basic unit)
3
−
+
7
0V
+6V
0V
+6V
Recommended wire
0.2mm
2
(7/0.18) with shield
Cable connection (J37)
J37
JA4L
Connector
PCR-E20FS or PCR-E20FA
Housing
PCR-V20LA
Shielded
