EDIT.
FANUC LTD
SHEET
DRAW. NO.
CUST.
TITLE
/
DESCRIPTIONDESIG.DATE
A
-65551EN/01
4. Initial setting of servo parameter
Set the following of analog servo axis.
Parameter
number
Description Data
No.2000 Automatic setting 00000000
No.2020 Motor type 50
No.2001 AMR 00000000
No.1820 CMR
No.2084 F⋅FG(Numerator)
No.2085 F⋅FG(Denominator)
Set the value similar to the one of digital
servo according to mechanical system.
No.2022 Rotation direction 111(CCW)or−111(CW)
No.1821 Reference counter size Set the number (after F⋅FG) of pulse per one
motor revolution as digital servo.
No.2023 Feedback pulse for velocity
detection
Set value =1536.797×E
E : the voltage (V) proportional to the
1000rpm velocity command
No.2024 Feedback pulse for position
detection
Set the number (before F⋅FG) of pulse per one
motor revolution as digital servo.
5. Power OFF/ON
6. Setting to validate the analog servo interface function
Set the following of analog servo axis.
