B-70315EN/02 3.INSTALLATION

- 87 -

3.4 PREPARATION PRIOR TO SHIPMENT

For shipment and transportation, follow the steps explained below.

(1) Disconnect all CNC connecting cables.

(2) Disconnect the power cable and ground cable. Cover the cable

inlet holes with tape or the like.

(3) Remove the laser gas pipes, and attach blanking plugs to the

pipes to prevent dust from entering.

(4) Detach the cooling water piping, and remove the water. For

details of how to remove the cooling water, see Subsection 3.4.2.

CAUTION

Any residual cooling water may result in corrosion

or clogging; furthermore, if any residual cooling

water freezes, a pipe or the oscillator itself may be

damaged.

(5) Install the resonator clamp and shutter clamp, and fit a blanking

cap onto the beam outlet.

(6) Check the security of all connectors and printed circuit boards.

Install protective covers.

(7) Check that all removed mounting screws are reinstalled.

(8) Install the panels to the cabinet.
