Laser C1000/C2000/C4000/C5000/C6000-Model E Europe Maintenance manual Page 356

Maintenance manual
E.PARAMETER LIST APPENDIX B-70315EN/02
- 336 -
E.18 LASER GAS MIXER FUNCTION
15710 Wait time for checking the remaining amount in the gas cylinder
[Data type] Word
[Unit of data] sec
[Valid data range] 0 to 32767
[Standard setting value]
Wait time when the remaining amount in the gas cylinder is checked
15711 Gas mixture wait time
[Data type] Word
[Unit of data] min
[Valid data range] 0 to 32767
[Standard setting value] 60
Time required until gas mixture is complete and the mixed gas can be
supplied after gases are filled in the tank.
15712 Gas mixer evacuation time
[Data type] Word
[Unit of data] min
[Valid data range] 0 to 32767
[Standard setting value] 30
Set the time required for evacuating the mixer. This value is also used
for the time required for evaluation for leakage check.
15713 Helium exhaust time
[Data type] Word
[Unit of data] msec
[Valid data range] 0 to 32767
[Standard setting value]
Time required for exhausting the Helium gas from piping before the
next gas is filled after the helium gas is filled
15714 Nitrogen and CO
2
exhaust time
[Data type] Word
[Unit of data] msec
[Valid data range] 0 to 32767
[Standard setting value]
Time required for exhausting the nitrogen gas or CO
2
from the piping
before the next gas is filled after that gas is filled
