B-70315EN/02 APPENDIX E.PARAMETER LIST
- 321 -
15212 Maximum specifiable power when the duty ratio is not clamped
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 32767
If PRM No. 15213 does not clamp the duty ratio to 50%, and a
specified power after power compensation and power feedback
processing exceeds the setting in this parameter, the power is clamped
to the setting. If a value of 0 is set, the setting of parameter No. 15207
is set.
15213 Duty ratio clamp criterion
[Data type] Word
[Unit of data] W
[Valid data range] 0 to 7000
When a specified power multiplied by an override value exceeds the
value set in this parameter, the duty ratio is clamped to 50% (fixed
value), and the peak value is clamped to the value set in PRM No.
15210. If a value of 0 is set, the setting of parameter No. 15210 is set.
15214 Maximum specifiable CW-YAG laser frequency
[Data type] Word
[Unit of data] Hz
[Valid data range] 0 to 32767
When a CW-YAG laser oscillator is used, the specified frequency is
clamped to this value.
15215 Power input calibration coefficient
[Data type] Word
[Unit of data] W
[Valid data range] 102(0.1×2
10
) to 10240(10×2
10
)
(If 0 is specified, 1024 (1×2
10
) is assumed.)
Set the power input compensation factor.
15216 Power display filter time constant
[Data type] Word
[Unit of data] msec
[Valid data range] 0 to 32767
This is the filter time constant with which fluctuation in power display
is suppressed.
