B-70315EN/02 APPENDIX E.PARAMETER LIST

- 331 -

15300 Power command 0 when all discharge tubes are used

15301 Power command 1 when all discharge tubes are used

15302 Power command 2 when all discharge tubes are used

15303 Power command 3 when all discharge tubes are used

15304 Power command 4 when all discharge tubes are used

15305 Power command 5 when all discharge tubes are used

15306 Power command 6 when all discharge tubes are used

15307 Power command 7 when all discharge tubes are used

15308 Power command 8 when all discharge tubes are used

[Data type] Word

[Unit of data] W

[Valid data range] 0 to 32767

[Standard setting value] Refer to the parameter data sheet delivered with the machine.

Sequentially set the output setting starting from 0 for each table

interval when all discharge tubes are used.
