B-70315EN/02 5.TROUBLESHOOTING

- 131 -

ALM No.4124

OVER COOL

The oscillator has a low temperature sensor on the side of

resonator plate to measure the temperature of cooling water.

Alarm output condition

This alarm is issued if the cooling water temperature becomes less than

20℃ after laser warm-up driving.

Related data

DGN.961#1 *CAT Low Temperature Sensor

No. Cause of trouble Solution

1 Faulty chiller unit Check temperature setting.

Or fix the chiller unit.

2 Faulty low temperature

sensor

Replace the temperature sensor.

3 Faulty intermediate PCB Replace the intermediate PCB.

4 Faulty interface PCB Replace the interface PCB.

5 Anomaly of connection

cable

Check the cable connections.

ALM No.4132

PARAMETER WAS CHANGED

This alarm is issued if a parameter is changed.

Alarm output condition

This alarm is issued if parameter No. 15223, 15242, or 15243 is

changed after the discharge start ready (LRDY) state is established.

Related data

PRM.15223 Specified discharge bias value

PRM.15242,15243 Setting of the pressure in the tube during oscillation

Before turning on the discharge start signal (HV ON), press the

RESET key to release this alarm.
