FANUC Series 30i/31i/32i Additional Manual Page 10

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
FANUC Series 30
i
/31
i
/32
i
–MODEL A
IMPROVEMENT OF FILE OPERATION
ON THE PROGRAM FOLDER SCREEN
A
-90423E
Nov.30.2005
10/12
New design
Nov.30.2005
01
Page
Title
Draw
No.
Descri
p
tion
Copying or Moving Files in Separate Display
Procedure 1
・Selecting the copy or movement destination folder after selecting a file
1 Select EDIT mode.
2 Press function key
PROG
to display the program folder screen.
3 Press soft key [(OPRT)].
4 Press rightmost soft key [+] (continuous menu key) twice.
5 Press soft key [MULTI LIST] to display two folder views.
6 Select the folder including the file to be copied or moved in either of these views.
7 Press soft key [SELECT START].
8 Move the cursor to the target file with cursor keys.
9 Press soft key [SELECT] to select the file.
10 Select the other folder view by pressing the SHIFT key and cursor keys.
11 Press soft key [DEVICE CHANGE] to select the copy or movement destination device.
12 Select the target device with soft keys.
13 Move to the copy or movement destination folder on the selected device.
14 Press soft key [COPY] to copy the selected file to the destination folder or press soft key
[MOVE] to move the selected file to the destination folder.
Procedure 2
・Selecting the copy or movement destination folder before selecting a file
1 Select EDIT mode.
2 Press function key
PROG
to display the program folder screen.
3 Press soft key [(OPRT)].
4 Press rightmost soft key [+] (continuous menu key) twice.
5 Press soft key [MULTI LIST] to display two folder views.
6 Select the folder including the file to be copied or moved in either of these views, switch
to the other folder view with the SHIFT key and cursor keys, select the copy or
movement destination folder in the folder view.
7 Switch to the folder view where the copy or movement destination folder was selected
with the SHIFT key and cursor keys.
8 Press rightmost soft key [+] (continuous menu key).
9 Press soft key [SELECT START].
10 Move the cursor to the target file with cursor keys.
11 Press soft key [SELECT] to select the file.
12 Press soft key [COPY] to copy the selected file to the folder selected in another folder
view or press soft key [MOVE] to move the selected file to the folder.
