FANUC Series 30i/31i/32i Additional Manual Page 6

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
FANUC Series 30
i
/31
i
/32
i
–MODEL A
IMPROVEMENT OF FILE OPERATION
ON THE PROGRAM FOLDER SCREEN
A
-90423E
Nov.30.2005
6/12
New design
Nov.30.2005
01
Page
Title
Draw
No.
Descri
p
tion
Switching of Folder Views where File Operation is Enabled in Separate Display
To switch the folder view where file operation is enabled between separated folder views,
follow the procedure below.
In the folder view where file operation is enabled, the cursor appears in the file list.
Procedure
1 When the MDI SHIFT key and cursor key [
↓
] are pressed in situations where file
operation in the upper folder view is enabled, file operation in the lower folder view
becomes enabled.
2 When the MDI SHIFT key and cursor key [
↑
] are pressed in situations where file
operation in the lower folder view is enabled, file operation in the upper folder view
becomes enabled.
NOTE
・ When the MDI SHIFT key and cursor key [↑] are pressed in situations
where file operation in the upper folder view is enabled in procedure, file
operation in the lower folder view becomes enabled.
・ When the MDI SHIFT key and cursor key [↓] are pressed in situations
where file operation in the lower folder view is enabled in procedure, file
operation in the upper folder view becomes enabled.
