FANUC Series 30i/31i/32i Additional Manual Page 8

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
FANUC Series 30
i
/31
i
/32
i
–MODEL A
IMPROVEMENT OF FILE OPERATION
ON THE PROGRAM FOLDER SCREEN
A
-90423E
Nov.30.2005
8/12
New design
Nov.30.2005
01
Page
Title
Draw
No.
Descri
p
tion
Parameters
#7 #6 #5 #4 #3 #2 #1 #0
11318 MLD
[Input type] Parameter input
[Data type] Bit system common type
#1 MLD On the program folder screen, separate display is
0: Disabled.
1: Enabled.
NOTE
This parameter is enabled for 10.4- and 15-inch monitors.
Restrictions
・Devices that can be selected at the same time in separate display
The devices that can be selected at the same time in separate display are shown below.
・ CNC MEM
・ MEM CARD (binary format)
・ Data server
A device other than the above cannot be selected and displayed at the same time in both of
folder views.
When a device other than the above was selected as the device before separate display starts,
the same folder cannot be displayed in both the upper folder and the lower folder due to the
above restriction. Therefore, the lower folder view includes the items in the folder selected
as the foreground folder.
・Monitors that supports separate display
The 10.4- and 15-inch monitors support separate display.
Previous page
Next page
