FANUC Series 30i/31i/32i Additional Manual Page 12

Additional Manual
Edit
Apprv.Desig.
Date
Design
Date
FANUC Series 30
i
/31
i
/32
i
–MODEL A
IMPROVEMENT OF FILE OPERATION
ON THE PROGRAM FOLDER SCREEN
A
-90423E
Nov.30.2005
12/12
New design
Nov.30.2005
01
Page
Title
Draw
No.
Descri
p
tion
・The copy or movement destination folder is changed during selection.
・Selection is finished with soft key [SELECT END] and selection is started again with soft
key [SELECT START].
Restrictions
・Operation mode
Select the EDIT mode before copying or moving files operations between different devices.
And, for multi-path systems, place all paths in the EDIT mode.
If an attempt is made to perform a copy or movement in any mode other than EDIT mode, the
warning message "CHANGE TO EDIT MODE" appears.
・File operation restrictions on devices
A copy or movement between the following devices is possible.
・ CNC MEM
・ MEM CARD (binary format)
(However, this device can only be selected as the copy source folder from which a file is
read.)
・ Data server
For devices other than the above, a copy or movement between them is impossible.
A copy or movement to a device other than the above or the MEM CARD or movement from
the MEM CARD cannot be performed.
If an attempt is made to perform a copy or movement, the warning message " CAN NOT
COPY/MOVE" appears.
・Copying or moving a folder
A folder cannot be copied or moved.
When an attempt is made to select a folder as the copy or movement target, the warning
message " DISABLE TO SELECT" appears.
Caution
NOTE
Once a copy or movement starts, the operation cannot be stopped.
Therefore, sufficiently check the files or folders to be copied or moved
before.
