0i/0i Mate - Model C Descriptions Page 33

Descriptions
B–64112EN/01
2. LIST OF SPECIFICATIONSGENERAL
7
Item
Series 0i MateSeries 0i
SpecificationsItem
TCMCPCTCMC
Specifications
Backlash compensation for each rapid
traverse and cutting feed
f f f f f
Stored pitch error compensation f f f f f
Bi–directional pitch error compensation l l l — —
Position switch f f f f f
Unexpected disturbance torque
detection function
f f f — —
Control axis detach f f — f f
Linear scale I/F with absolute address
reference mark
l l l — —
Linear scale with absolute address
reference mark expansion
l l — — —
Temporary absolute coordinate setting l l — — —
Operation
Automatic operation (memory) f f f f f
DNC operation Reader/puncher interface is required. f f f f f
DNC operation with Memory Card PCMCIA Card Attachment is required. f f f f f
MDI operation f f f f f
Schedule function f f f f f
Program number search f f f f f
Sequence number search f f f f f
Sequence number comparison and
stop
f f f f f
Program restart f f — f f
Manual intervention and return f f — f f
Retraction for rigid tapping f — — f —
Buffer register f f f f f
Dry run f f f f f
Single block f f f f f
JOG feed f f f f f
Manual reference position return f f f f f
Reference position setting without
DOG
f f f f f
Reference position setting with
mechanical stopper
f f — f f
Reference position shift f — f — —
Manual handle feed MC, PC : Max. 3 units TC : Max. 2 units f f f f f
Manual handle feed rate 1, 10, m, n m: 0 to 127, n: 0 to 1000 f f f f f
Manual handle interruption f f f f f
Manual handle I/F for I/O Link β l l l l l
Incremental feed 1, 10, 100, 1000 f f f f f
Jog and handle simultaneous mode f f f f f
Interpolation functions
Positioning G00 (Linear interpolation type positioning is possible) f f f f f
Single direction positioning G60 f — — f —
Exact stop mode G61 f — f f —
Exact stop G09 f — f f —
Linear interpolation f f f f f
Circular interpolation Multi–quadrant is possible f f f f f
Dwell
Dwell in seconds and dwell in revolution
(In case of dwell in revolution for M series, threading,
synchronous cutting function is required.)
f f f f f
Polar coordinate interpolation — f — — f
Cylindrical interpolation f f — — f
Helical interpolation
Circular interpolation plus max. 2 axes linear
interpolation
f l f f —
Threading, synchronous cutting f f — f f
Multiple threading — f — — f
Threading retract — f — — f
Continuous threading — f — — f
