Series 0i/0i Mate - Model B Connection manual (Hardware) Page 191

Connection manual (Hardware)
B–63833EN/03
9. CONNECTION TO FANUC I/O Link
177
If a customer wishes to partially modify the standard key sheet, he or she
can customize the key sheet.
D The machine tool builder prints out the desired key indication on a
sticker prepared by the machine tool builder.
D Apply the sticker on the standard key sheet.
D Remove the screws from the front side, remove the escutcheon, apply
a transparent key sheet on the standard key sheet, taking care not to get
dust or air caught between them. Finally, put back the escutcheon.
D The transparent key sheet is an option.
Specification:
A02B–0299–K210 (set of three transparent key sheets)
Size of the sticker
13 mm
13 mm
NOTE
If a small machine operator’s panel customized in this way
is to be maintained (replaced), the application of the sticker
must be performed by the customer. The customer must
prepare a sticker. Once peeled off, the transparent sheet
cannot be reused. Another transparent sheet must be
used.
The keyboard of this operator’s panel is in a matrix configuration. If three
or more keys are pressed on the DI matrix, DIs not entered will be entered
because of the circulation of the current. It is possible to take action
against this malfunction using a Ladder program.
See Subsection 9.4.9.
9.5.10.2
Customization of the key
sheet
9.5.11
Others
