B–63833EN/03

9. CONNECTION TO FANUC I/O Link

241

Installation specifications

Ambient temperature During operation 0° to 58°C

During storage and transportation –20°C to 60°C

Temperature change Max. 1.1°C/min.

Relative humidity Normal: 75% or less

Short term (1 month or less): 95% or less

Vibration During operation: 0.5 G or less

Environment Ordinary machining factory environment (Special

consideration is required when installing the module in

a dusty place or where highly concentrated cutting

lubricant or organic solvent is used.)

Other requirements (1) Install the I/O module in a fully enclosed cabinet.

Ordering specifications

Item Specification Remarks

Operator’s panel

I/O module

(with MPG interface)

A20B–2002–0520 DI: 48 points

DO: 32 points

MPG interface is supported.

Power magnetics panel

I/O module

(without MPG interface)

A20B–2002–0521 DI: 48 points

DO: 32 points

MPG interface is not

supported.

Fuse (replacement part) A03B–0815–K001 1 A

Module specifications

Item Specification Remarks

DI points 48 points 24 V input

DO points 32 points 24 V source type output

CNC interface FANUC I/O Link

connection

Up to 16 modules can be

connected as CNC slaves.

Or, a maximum of 1024 points

can be supported on both the

input and output sides.

MPG interface Max. 3 units MPG interface can be used

only for the i series CNC.

9.8.8

Specifications
