FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual Page 35

Additional Manual
Ed.
Ed.Ed.
Ed. Date
DateDate
Date Design
DesignDesign
Design Description
DescriptionDescription
Description
Date
DateDate
Date 2003.03.07 Desig.
Desig.Desig.
Desig. Kageyama Apprv.
Apprv.Apprv.
Apprv.
35
/
131
FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
DISP UNIT
The unit which can be set is changed by the value of operation and Input 1.
The list of numerical value to set up is displayed in “the candidate”.
Input condition
1) The number that is displayed on the candidate can be selected.
(Candidate display is different by the channel setting. )
« Reference » The indication unit condition which can be selected.
OPERATION Choice condition
YT The unit which is applicable to the unit classification specified in the channel of the input
1
DIFF 1 The unit which is applicable to ANGLEVELOC in the case of the unit which is applicable
to VELOCITY, ANGLE when the unit classification specified in the channel of the input
1 is LENGTH
DIFF 2 The unit which is applicable to ANGLEACCEL in the case of the unit which is applicable
to ACCEL, ANGLE when the unit classification specified in the channel of the input 1 is
LENGTH.
TANGENT / N The unit that unit classification corresponds to VELOCITY.
SMOOTH The unit that unit classification corresponds to LENGTH or ANGLE.
SYNCHRO The unit that unit classification corresponds to LENGTH, ANGLE or UNKNOWN.
« Reference » Unit classification list
Unit classification Unit
TIME Sec / msec / µsec
LENGTH m / mm / µm / nm / inch
ANGLE deg / mdeg
VELOCITY Mm/sec / mm/min / m/sec / m/min / inch/sec inch/sec / inch/min
ANGLEVELOC deg/sec / deg/min / l/sec / l/min
ACCEL Mm/sec/sec / mm/min/min / m/sec/sec / m/min/min / inch/sec/sec / inch/sec/sec
ANGLEACCEL deg/sec/sec / deg/min/min / l/sec/sec / l/min/min
CURRENT A(p)
FREQUENCY Hz
LOGIC % / pulce / bit
UNKNOWN -- / unknown
