FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
4.1 Tuning of square
4.1.1 Preparation of the program
« Reference program »
G91G94
N1 G01X20.000F2000.000
G01Y-20.000F2000.000
G01X-20.000F2000.000
G01Y20.000F2000.000
G04X1.
N999 G04X1.
M02
4.1.2 Preparation of data measurement
1) Soft key [XY] pushed.
2) Soft key [SAMPL] pushed.
3) Soft key [DATA] pushed.
4) The soft key [CH SET] is pushed and the data to acquire is set.
« Reference setting »
It is set up to output position feedback integrated value in CH1, 2.
Axis Kind Unit CONV.
COEF
CONV.
BASE
Origin
Value
CH1 1 5 (POSF) 4 (mm) 0.001 1.000 0.000
CH2 2 5 (POSF) 4 (mm) 0.001 1.000 0.000
CH3 0
−−−−−
CH4 0
−−−−−
5) Soft key [SAMPL] pushed.
6) The following data are set.
DATA POINT 10000
TRIGGER PATH 1
SEQ. NO 1
SAMPLING CYCLE (SERVO) 7 (1ms)
SAMPLING CYCLE (SPINDLE) 7 (1ms)
AUTO SCALING 1
