FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Operation of the graph
The operation is done by the softkey.
[↑] : A waveform is moved to the vertical axis side upward direction.
[↓] : A waveform is moved to the vertical axis side downward direction.
[←] : A waveform is moved in the horizontal axis side left direction.
[→] : A waveform is moved in the horizontal axis side right direction.
[HRZMIN] : The horizontal axis of all the waveform is expanded and displayed.
[HRZMOU]: The horizontal axis of all the waveform is reduced and displayed.
[AUTSCL] : A scale is adjusted automatically toward all the Draw graphs, and a
graph is made be to put within the display range.
But, each item of scale setting is between 0 - 99999999 (eight digits of 9)
in the range that it is adjusted.
In case that the graph is out of display range, the display unit of
operation & graph setting is need to be adjust.
[VRZMIN] : The vertical axis of all the waveform is expanded and displayed.
[VRZMOU]: The vertical axis of all the waveform is reduced and displayed.
[D1DISP] : The display or nondisplay is changed about the Draw1 waveform.
[D2DISP] : The display or nondisplay is changed about the Draw2 waveform.
[COMNT1] : Maximum 32-character comment can be inputted.
(Even an INPUT key can input only comment 1.)
And, input of a comment is displayed in all graphic display.
[COMNT2] : Maximum 32-character comment can be inputted.
And, input of a comment is displayed in all graphic display.
