FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Operation
The list of numerical value to set up in “the candidate" is displayed
The details of the computation is as follows.
Selecting number Contents Remarks
1 N/A It does not use it
11 XY
Input condition
1) The selecting number on the candidate can be inputted by the following condition.
N/A … input condition no
XY … channel setting with the binding of the position system be being
done 2 or more pieces.
Input 1
By the value of operation or coordinate conversion, setting value is changed.
The list of numerical value to set up is displayed in “the candidate”.
The details of input 1 is as follows.
Selecting number Contents
1 CH 1
2 CH 2
3 CH 3
4 CH 4
Input condition
1) The number that is displayed on the candidate can be selected.
( Candidate display is different by the channel setting. )
« Reference » The channel condition which can be chosen
Operation CONV Selecting condition
XY Normal
Angular
Measurement channel as the location information relation
( POSF / ABS / PCPOS / CSPOS )
Polar Measurement channel as the mm/m/µ m/nm/inch of the unit
