FS16i/18i/21i-TB/MB Servo Guide Mate Specification (Draft) Additional Manual Page 63

Additional Manual
Ed.
Ed.Ed.
Ed. Date
DateDate
Date Design
DesignDesign
Design Description
DescriptionDescription
Description
Date
DateDate
Date 2003.03.07 Desig.
Desig.Desig.
Desig. Kageyama Apprv.
Apprv.Apprv.
Apprv.
63
/
131
FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Operation
The list of numerical value to set up is displayed in “the candidate”.
The details of the computation is as follows.
Selecting number Contents Remarks
1 N/A Does not use
21 CIRCLE
Input condition
1) The number displayed in the candidate can be selected by the following condiditon.
N/A …input condition no
CIRCLE …Two and more setup of the position by channel set screen is
needed.
Input 1
By the value of operation or coordinate conversion, setting value is changed.
The list of numerical value to set up is displayed in “the candidate”.
The details of input 1 is as follows.
Selecting number Contents
1 CH 1
2 CH 2
3 CH 3
4 CH 4
Input condition
1) The number that is displayed on the candidate can be selected.
( Candidate display is different by the channel setting. )
« Reference » The channel condition which can be chosen
Operation CONV Selecting condition
CIRCLE Normal
Angular
Measurement channel as the location information relation
(POSF / ABS / PCPOS / CSPOS )
Polar Measurement channel as the mm/m/µ m/nm/inch of the unit
