FANUC Series 16i/18i/21i-TB/MB
SERVO GUIDE Mate Specification
A
-79087EN
Drawing No.
Title
Page
Input 2
By the value of operation or coordinate conversion, setting value is changed.
The list of numerical value to set up is displayed in “the candidate”.
The details of input 2 is as follows.
Selecting number Contents
1 CH 1
2 CH 2
3 CH 3
4 CH 4
Input condition
1) The number that is displayed on the candidate can be selected.
( Candidate display is different by the channel setting. )
« Reference » The channel condition which can be chosen
Operation CONV Selecting condition
XY Normal
Angular
Measurement channel as the location information relation
( POSF / ABS / PCPOS / CSPOS )
Polar Measurement channel as deg of the unit
DISP UNIT
Only the correct value is set to “Input 1”, “4:mm” can be set.
The list of numerical value to set up is displayed in “the candidate”.
Input condition
1) The number that is displayed on the candidate can be selected.
( Candidate display is different by the channel setting. )
Previous page
Next page
