3.3 Customization of conversion rule
Following conversion rules can be customized by editing
ConvRuleChar.txt if necessary.
- In conversion of symbol to variable name, some characters are
replaced according to the rule described in the file.
1) Character that cannot be used in variable name is used in
conversion source data, it is replaced to other character.
2) Japanese is used in description, it is replaced to series of a
character.
3) Prefix of variable name (default setting is 'SYM_' ) is added.
- In message conversion, Japanese-formatted message data is replaced
to series of a character according to the rule described in the file.
Conversion rules for functional instruction can be customized by
editing ConvRuleLad.txt.
This file also includes some additional rules which may increase the rate
of the conversion if some instructions are used on certain conditions in
the source program. Such additional rules are not activated but are
commented out by default. If they can be applied to the source program,
please try to tune the conversion rule by editing the applicable lines in
the ConvRule.txt to delete ";;" at the beginning of each line.
Example of customizing:
If you assume that DIFU can be converted to R_TRIG with
DUMMY_PARAM which has no reference, delete ";;" as follows.
;;[DIFU] [DIFU]
;;InstFunc=FIXED_NAME InstFunc=FIXED_NAME
;;InstName1=R_TRIG InstName1=R_TRIG
;;ConditionCount=1 ConditionCount=1
;;Condition1=PMC_CONDITION_1 Condition1=PMC_CONDITION_1
;;ParamCountInsideBox=1 ParamCountInsideBox=1
;;ParamCountOutsideBox=0 ParamCountOutsideBox=0
;;IecParam1=INSERT_DUMMY
⇒
IecParam1=INSERT_DUMMY
