20i-MB Connection manual (Hardware) Page 222

Connection manual (Hardware)
8. CONNECTION TO FANUC I/O Link
B–64193EN/01
210
Item Specification Note
General–purpose DI points 32 points 24VDC type input
General–purpose DO points 8 points 24VDC type output, non–insulating
Keyswitches of Machine operator’s panel 55 keys Matrix DI
LED Color : Green Attached to all keyswitches, Matrix DO
MPG interface Max. 3 units
Interface to CNC FANUC I/O Link connection Max. 16 modules or total points max.
1024/1024 will be available.
Item
Sub panel specification
Note
Item
A B
Note
Override rotary switch 2 2 5 bit Gray code output (with a parity bit)
Emergency stop switch 1 1 Number of Contact : 4 (Contact a 2,
Contact b 2)
M3.5 Screw
Program protect key 1 1
ON/OFF switch ON/OFF –
Voltage Capacity Note
24VDC"10% (from Power connector
CA64, including momentary values)
Momentary values and ripples are also
included in "10%.
0.4A Including all DI consumption
8.8.7.3
Main panel B, B1
specification
8.8.7.4
Sub panel A, B1
specification
8.8.7.5
Power supply
specification
