20i-MB Connection manual (Hardware) Page 277

Connection manual (Hardware)
B–64193EN/01
B. 20–PIN INTERFACE CONNECTORS AND CABLES
265
This section provides supplementary information about the
recommended (FANUC–approved) 20–pin interface connectors used
with the following target model.
FANUC i series
Models: PCR–EV20MDT (Honda Tsushin)
52618–2011 (Molex Japan)
These board–mounted connectors have been specially developed to
achieve the high packing density required for FANUC products. As
explained in the following subsection, Honda PCR series connectors can
be used as cable connectors because the mating mechanism of the newly
developed connectors is compatible with that of the Honda PCR series
connectors. To support this specification extensively, many connector
manufacturers are now developing custom–tailored cable connectors.
(Note that these cables cannot be used with screw–fixing cable connector
housings.)
Models: PCR–E20MDK–SL–A (Honda Tsushin)(straight connector)
PCR–E20LMDETZ–SL (Honda Tsushin)
(right–angled connector)
These connectors are used for the main and option boards of this CNC.
As cable connectors, they are compatible with screw–fixing connector
housings as well as the spring locking connector housings.
B.1
OVERVIEW
B.2
ADDITIONAL
TARGET MODEL
B.3
BOARD–MOUNTED
CONNECTORS
B.3.1
Vertical–type
Connectors
B.3.2
Straight and
Right–angled
Connectors (for Spring
and Screw–fixing
Connector Housings)
