3. INSTALLATION
B–64193EN/01
18
Table 3.4.2 (a) Heat output
Unit
Heat output (W) Remarks
LCD–mounted
type control unit
Without option slots 33W (*1)
type control unit
With 2 option slots 37W (*1)
Option board (*2)
Serial communication
board (remote buffer)
6W
Data server board 9W
NOTE
1 The liquid–crystal display and MDI unit are included. Option
boards are not included.
2 When option boards are used, the total heat output of the
selected option boards must not exceed the following value:
Rack type Total heat output
2–slot rack 26W
Table 3.4.2 (b) Heat output (peripheral units)
Unit
Heat output (W) Remarks
MDI unit 0W
Operator’s panel I/O module 12W (*1)
Connector panel I/O module (basic) 8W (*1)
Connector panel I/O module
(additional)
5W (*1)
Separate detector interface unit 9W Basic 4–axis unit
only(*2)
NOTE
1 The indicated values are when 50% of the module input
signals are ON.
2 Heat output generated within the separate detector is not
included.
3.4.2
Heat Output of Each
Unit
