PROGRAMMING

B–64114EN/01

14. COMPENSATION FUNCTION

201

Table 14.2.3(b) Tool wear offset

Wear

offset

number

OFGX

(X–axis

wear offset

amount)

OFGZ

(Z–axis

wear offset

amount)

OFGR

(Tool nose

radius

wear offset

value)

OFT

(Imaginary

tool nose

direction)

OFGY

(Y–axis

wear offset

amount)

W01

W02

W03

W04

W05

0.040

0.060

0.020

0.030

0.20

0.010

0.020

The tool nose radius compensation value during execution is the sum of

the geometry offset and the wear offset.

OFR=OFGR+OFWR

The imaginary tool nose direction may be set for either the geometry

offset or the wear offset.

However, the last designated direction later is effective.

A offset number is specified with the same T code as that used for tool

offset. For details, see Subsec. II–14.1.2.

NOTE

When the geometry offset number is made common to the

tool selection by the parameter LGT(No.5002#1)setting

and a T code for which the geometry offset and wear offset

number differ from each other is designated, the imaginary

tool nose direction specified by the geometry offset number

is valid.

Example) T0102

OFR=RFGR

+OFWR

OFT=OFT

However, the direction specified by the wear offset number

becomes enabled depending on the parameter WNP

(No.5002#7) setting.

The range of the offset value is an follows :

Increment system metric system Inch system

IS–B 0 to"999.999 mm 0 to"99.9999 inch

IS–C 0 to"999.9999 mm 0 to"99.99999 inch

The offset value corresponding to the offset number 0 is always 0.

No offset value can be set to offset number 0.

D Tool nose radius

compensation

D Imaginary tool nose

direction

D Command of offset value

D Setting range of offset

value
