APPENDIX

B–64114EN/01

G. ALARM LIST

805

SVPM

STATUS1

indica-

tion(*1)

Faulty location and remedyDescription

12 When a spindle synchronization control command

is input, another mode (Cs contour control, servo

mode, or orientation) is specified.

During execution of a spindle synchronization control

command, do not specify another mode. Before entering

another mode, cancel the spindle synchronization con-

trol command.

14 SFR (forward rotation command) and SRV (re-

verse rotation command) are input at the same

time.

Input either of the commands.

17 The speed detector parameter settings (bits 2, 1, 0

of parameter No. 4011) are invalid. No speed de-

tector corresponds to the settings.

Check the parameter settings.

18 When the parameter settings are made not to use

the position, meaning that position control is not

performed (bits 3, 2, 1, 0 of parameter No. 4002 =

0, 0, 0, 0), orientation by a position coder is speci-

fied.

Check the parameter settings and input signal.

24 For continuous indexing in orientation by a position

coder, an incremental operation (INCMD = 1) is first

performed, and an absolute position command

(INCMD = 0) is then input.

Check INCMD (incremental command). Before absolute

position commands are executed successively, absolute

position command orientation must be performed first.

29 The parameter settings are made to use the short-

est time orientation function (bit 6 of parameter No.

4018 = 0, parameters No. 4320 to 4323 ( 0).

The shortest time orientation function cannot be used.

Use orientation by a normal method.

31 This hardware configuration does not allow the

spindle FAD function to be used. In this case, the

motor is not excited.

Check the CNC model.

33 This hardware configuration does not allow the

spindle EGB function to be used. In this case, the

motor is not excited.

Check the CNC model.

34 The spindle FAD function and spindle EGB func-

tion are both enabled. In this case, the motor is not

excited.

These two functions cannot be used at the same time.

Enable only either of them.

NOTE*2

SVPM contact signal

Between ESP and +24V on JX4 Contact open: Emergency stop

Contact closed: Normal operation

11) ALARM FOR FANUC SERVO MOTOR β series I/O Link Option

Alarm for FANUC SERVO MOTOR β series I/O Link Option can be confirmed by Power Mate CNC Manager

function.

Number Alarm type

000 to 299 Program or setting alarm

300 to 399, 401 Pulse coder alarm

400 to 499 (except 401) Servo alarm

500 to 599 Overtravel alarm

— System alarm or I/O Link alarm
