0i-TC Operators manual Page 618

Operators manual
OPERATION11. SETTING AND DISPLAYING DATA
B–64114EN/01
592
Procedure to reset all axes
1 Press soft key [(OPRT)].
2 Press soft key
[ORIGIN].
3 Press soft key
[ALLEXE].
The relative coordinates for all axes are reset to 0.
Bits 4 (DRL) and 5 (DRC) of parameter 3104 can be used to select
whether the displayed values include tool offset and tool nose radius
compensation.
Bit 3 of parameter 3104 is used to specify whether the displayed positions
in the relative coordinate system are preset to the same values as in the
workpiece coordinate system when a coordinate system is set by a G50
(G code system A) or a G92 (G code system B or C) command or when
the manual reference position return is made.
ORIGIN
EXEC
RELABS
ALL
(OPRT)
ALLEXE
D Display including
compensation values
D Presetting by setting a
coordinate system
Previous page
Next page
