Panel i, Maintenance Manual Additional Manual Page 5

Additional Manual
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
5
/
30
DESCRIPTION DESIG. DATE
FANUC PANEL i
Maintenance Manual
A
-83138E
2. List of the PCBs, Units, Maintenance Supplies and Tools
2.1. List of PCBs
(1) Main PCB.
CNC Unit LCD type Specification of
Main PCB
Applied Basic Unit
10.4”/12.1”
A20B-8100-0930 A08B-0084-B001~4, -B011~4
A13B-0196-B001~4, -B011~4
PANEL i
15.0” A20B-8100-0931 A08B-0084-B021, -B023
A13B-0196-B021, -B023
160 i
/180 i
/210 i
PANEL i for Automotive 15.0” A20B-8100-0934 A08B-0084-B400~3, -B410~3
A13B-0196-B400~3, -B410~3
10.4” A20B-8100-0935
A08B-0084-B501~4
A13B-0196-B502, -B504
300 i PANEL i
15.0” A20B-8100-0936
A08B-0084-B521~4
A13B-0196-B522, -B524
PANEL i for Automotive 15.0”
A08B-0084-B422~3, -B432~3
A13B-0196-B422~3, -B432~3
(2) Backplane PCB
CNC Specification of
Backplane PCB
Applied Basic Unit
160 i
/180 i
/210 i
A20B-8002-0250 A08B-0084-B001~4
A08B-0084-B011~4
A08B-0084-B021, -B023
A08B-0084-B400~3, -B410~3
A13B-0196-B001~4
A13B-0196-B011~4
A13B-0196-B021, -B023
A13B-0196-B400~3, -B410~3
300 i A20B-8002-0330 A08B-0084-B422~3, -B432~3
A08B-0084-B501~4
A08B-0084-B521~4
A13B-0196-B422~3, -B432~3
A13B-0196-B502, -B504
A13B-0196-B522, -B524
(3) Inverter PCB
LCD type Specification of
Inverter PCB
Applied Basic Unit
10.4” A14L-0132-0001#A A08B-0084-B001~4
A08B-0084-B501~4
A13B-0196-B001~4
A13B-0196-B502, -B504
12.1” A14L-0143-0001#A A08B-0084-B011~4 A13B-0196-B011~4
15.0” A14L-0143-0002 A08B-0084-B021, -B023
A08B-0084-B400~3, -B410~3
A08B-0084-B422~3, -B432~3
A08B-0084-B521~4
A13B-0196-B021, -B023
A13B-0196-B400~3, -B410~3
A13B-0196-B422~3, -B432~3
A13B-0196-B522, -B524
