Panel i, Maintenance Manual Additional Manual Page 7

Additional Manual
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
7
/
30
DESCRIPTION DESIG. DATE
FANUC PANEL i
Maintenance Manual
A
-83138E
(2) Base Unit
Unit CNC LCD
type
I/O Link
Adapter
Softk
ey
Touch
panel
Specification of
Base Unit
*3
Applied Unit
None X X A08B-0084-D001 A08B-0084-B001 A13B-0196-B001
O X A08B-0084-D002 A08B-0084-B002 A13B-0196-B002
X O A08B-0084-D003 A08B-0084-B003 A13B-0196-B003
10.4”
LCD
O O A08B-0084-D004 A08B-0084-B004 A13B-0196-B004
None X X A08B-0084-D011 A08B-0084-B011 A13B-0196-B011
O X A08B-0084-D012 A08B-0084-B012 A13B-0196-B012
X O A08B-0084-D013 A08B-0084-B013 A13B-0196-B013
12.1”
LCD
O O A08B-0084-D014 A08B-0084-B014 A13B-0196-B014
None X X A08B-0084-D021 A08B-0084-B021 A08B-0196-B021
PANEL i 160 i
/180 i
/210 i
15.0”
LCD
X O A08B-0084-D023 A08B-0084-B023 A08B-0196-B023
None X X A08B-0084-D501 A08B-0084-B501
O X A08B-0084-D502 A08B-0084-B502 A13B-0196-B502
X O A08B-0084-D503 A08B-0084-B503
10.4”
LCD
O O A08B-0084-D504 A08B-0084-B504 A13B-0196-B504
None X X A08B-0084-D521 A08B-0084-B521
O X A08B-0084-D522 A08B-0084-B522 A13B-0196-B522
X O A08B-0084-D523 A08B-0084-B523
300 i
15.0”
LCD
O O A08B-0084-D524 A08B-0084-B524 A13B-0196-B524
None O X A08B-0084-D400 A08B-0084-B400 A13B-0196-B400
O O A08B-0084-D401 A08B-0084-B401 A13B-0196-B401
O X A08B-0084-D402 A08B-0084-B402 A13B-0196-B402
A08B-0084-B422 A13B-0196-B422
O O A08B-0084-D403 A08B-0084-B403 A13B-0196-B403
A08B-0084-B423 A13B-0196-B423
Exist O X A08B-0084-D410 A08B-0084-B410 A13B-0196-B410
O O A08B-0084-D411 A08B-0084-B411 A13B-0196-B411
O X A08B-0084-D412 A08B-0084-B412 A13B-0196-B412
A08B-0084-B432 A13B-0196-B432
PANEL i
for
Automoti
ve
160 i
/180 i
/210 i
or
300 i
15.0”
LCD
O O A08B-0084-D413 A08B-0084-B413 A13B-0196-B413
A08B-0084-B433 A13B-0196-B433
*3: Base Unit is a Unit that main PCB, backplane PCB, power supply PCB, inverter PCB, and rear cover
are excluded from Basic Unit. Consequently this unit consists chiefly of base plate, LCD unit, plastic
front cover, touch panel and softkey.
