Panel i, Maintenance Manual Additional Manual Page 6

Additional Manual
EDIT.
SHEET
DRAW. NO.
CUST.
TITLE
6
/
30
DESCRIPTION DESIG. DATE
FANUC PANEL i
Maintenance Manual
A
-83138E
(4) Touchpanel PCB
CNC Unit Specification of
Touchpanel PCB
Applied Basic Unit
160 i
/180 i
/210 i
PANEL I A20B-8001-0620 A08B-0084-B003~4
A08B-0084-B013~4
A08B-0084-B023
A13B-0196-B003~4
A13B-0196-B013~4
A13B-0196-B023
PANEL i
for Automotive
A20B-8002-0310 A08B-0084-B401, -B403
A08B-0084-B411, -B413
A13B-0196-B401, -B403
A13B-0196-B411, -B413
300 i PANEL i A20B-8002-0310 A08B-0084-B504
A08B-0084-B524
A13B-0196-B504
A13B-0196-B524
PANEL i
for Automotive
A08B-0084-B422, -B423
A08B-0084-B432, -B433
A13B-0196-B422, -B423
A13B-0196-B432, -B433
(5) Other PCB
Name Unit Specification of
PCB
Applied Basic Unit
Power Supply PCB
(Common to All unit) A20B-2100-0920 (Common to All unit)
I/O Link Adapter
PCB
PANEL i
for Automotive
A20B-8002-0270 A08B-0084-B410~1
A13B-0196-B410~1
I/O Link Adapter II
PCB
PANEL i
for Automotive
A20B-8002-0500 A08B-0084-B412~3
A08B-0084-B432~3
A13B-0196-B412~3
A13B-0196-B432~3
Softkey Adapter PCB PANEL i
for Automotive
A20B-1008-0320 A08B-0084-B410~1
A13B-0196-B410~1
2.2 List of Maintenance Units
(1) Drive Unit
Name Unit Specification of
Maintenance Unit
Supplied Order
Specification
Remark
3.5” HDD Unit
*1 *2
PANEL i for 160 i
/180 i /210 i
A08B-0082-C102#D A08B-0084-H100
PANEL i for
Automotive
A08B-0084-C120#D A08B-0084-H120
PANEL i for 300 i A08B-0084-C130#D A08B-0084-H130 In other case of below
condition
A08B-0084-C131#D A08B-0084-H131 In case of 10.4” LCD and
QWERTY MDI
FDD Unit (Common to All unit) A02B-0207-C009 - Panel Mount Type.
FDD Cables (Common to All unit) A02B-0207-K801 - Length = 1m.
FDD Drive (Common to All unit) A08B-0084-K001 - Only FDD.
CD-ROM Unit PANEL i for
Automotive
A08B-0084-K010 - Only CD-ROM drive.
*1: Specification of 3.5 HDD Unit may be updated.
*2: HDD unit is included fan unit for HDD, but is not included signal/power cables.
HDD, FDD or CD-ROM drive without FANUC designation may not work properly.
