2.3. List of CPU and Memory
Name Specification of
Maintenance Parts
Applied Order
Specification
Celeron733MHz A08B-0084-C210 A08B-0084-H010
PentiumIII 866MHz A08B-0084-C220 A08B-0084-H020
CPU
PentiumIII 1260MHz A08B-0084-C230 A08B-0084-H030
128MB
A76L-0500-0020
A08B-0084-H001
256MB
A76L-0500-0021
A08B-0084-H002
Memory
512MB
A76L-0500-0022
A08B-0084-H003
2.4. List of Maintenance Parts
Name Specification of
Maintenance Parts
Quantity
Fuse
A08B-0084-K020 1
Battery A02B-0200-K102 1
40mm fan unit for base unit. A08B-0084-K100 1
60mm fan unit for base unit A08B-0084-K101 1
Fan unit for HDD unit A08B-0084-K102 1
10.4” LCD A02B-0236-K116 1 LCD Backlight
12.1” LCD A02B-0236-K117 1
Pen for Touch Panel - A02B-0236-K111 1
Protection Sheet
for Touch Panel
10.4” LCD
for 300 i or
for 160 i /180 i /210 i with Softkey
A02B-0236-K110 1
10.4” LCD
for 160 i /180 i /210 i without Softkey
A02B-0236-K130 1
12.1” LCD A02B-0236-K118 1
15.0” LCD A08B-0082-K020 1
2.5. List of Maintenance Tools
Following tools may be needed to install the application software or maintenance.
Name Specification
101 Type A86L-0001-0210 Full Keyboard
(PS/2 I/F)
106 Type A86L-0001-0211
Mouse (PS/2 I/F) A86L-0001-0212
