Spindle alpha i Startup Manual Additional Manual Page 14

Additional Manual
2
01.05.24
14/41
Descri
p
tion
Design.
DateEd
01.03.23
SHEET
DRAW. No.
CUST.
TITLE
Y
okota
Y
okota
Newly designed
α
i series Spindle
Start-up Procedure
A
-53866E-387/02
FANUC LTD
1
(B) In case of using α position coder S
[Example system configuration]
M
i
(or MZ
i
sensor) in spindle motor
Spindle
JYA4
JYA2
SPM
TYPE B
α
position coder S
Direct connection, 1:1 connection by
gear or timing belt
Parameter No. Setting Description
4000 #0 Depends on
the
configuration
Direction of spindle and spindle motor rotation
4001 #4 Depends on
the
configuration
Spindle sensor mounting direction
4002 #3,2,1,0 0,1,0,0 Uses α position coders as spindle sensor
4003 #7,6,5,4 0,0,0,0 Setting of number of teeth of spindle sensor
4010 #2,1,0 Depends on
the detector
Setting of motor sensor type
4011 #2,1,0 Depends on
the detector
Setting of number of teeth of motor sensor
4056 to 4059 Depends on
the
configuration
Spindle-to-motor gear ratio data
(C) In case of using Mi sensor, BZi sensor
[Example system configuration 1]
MZ
i
sensor in spindle motor
Spindle
JYA2
SPM
TYPE A
