4. DESCRIPTION OF PARAMETERS
B–63510EN/01
146
5113
Spindle reverse–rotation M code in drilling canned cycle
[Data type] Byte
[Valid data range] 0 to 255
This parameter sets the spindle reverse–rotation M code in a drilling
canned cycle.
NOTE
M04 is output when “0” is set.
5114
Return or clearance value of drilling canned cycle G83
Return value of high–speed peck drilling cycle G73
[Data type] Word
[Unit of data]
Increment system IS-B IS-C Unit
Millimeter input 0.001 0.001 mm
Inch input 0.0001 0.0001 inch
[Valid data range] 0 to 32767
For 0i–MA, this parameter sets the return value in high–speed peck
drilling cycle G73 (G83 for 0i–TA).
q : Depth of cut
d : Return value
R point
Z point
q
q
q
d
d
G73 for 0i–MA
Fig.4.16.1 (a) High–speed Peck Drilling Cycle G73
