Series 0i - Model A Parameter manual Page 43

Parameter manual
B–63510EN/01
4. DESCRIPTION OF PARAMETERS
37
1421 F0 rate of rapid traverse override for each axis
[Data type] Word axis
[Unit of data]
[Valid data range]
Increment system
Unit of data
Valid data range
I
ncremen
t
sys
t
em
U
n
it
o
fd
a
t
a
IS-B IS-C
Millimeter machine 1 mm/min 30 to 15000 30 to 12000
Inch machine 0.1 inch/min 30 to 6000 30 to 4800
Rotaion axis 1 deg/min 30 to 15000 30 to 12000
Set the F0 rate of the rapid traverse override for each axis.
Rapid traverse override signal
Override value
ROV2 ROV1
O
verr
id
eva
l
ue
0 0 100%
0 1 50%
1 0 25%
1 1 F0
F0: Parameter 1421
1422 Maximum cutting feedrate for all axes
[Data type] 2–word
[Unit of data]
[Valid data range]
Increment system
Unit of data
Valid data range
I
ncremen
t
sys
t
em
U
n
it
o
fd
a
t
a
IS-B IS-C
Millimeter machine 1 mm/min 6 to 240000 6 to 100000
Inch machine 0.1 inch/min 6 to 96000 6 to 48000
Specify the maximum cutting feedrate.
A feedrate in the tangential direction is clamped in cutting feed so that it
does not exceed the feedrate specified in this parameter.
NOTE
To specify the maximum cutting feedrate for each axis, use
parameter No.1430 instead.
1423 Feedrate in manual continuous feed (jog feed) for each axis
[Data type] Word axis
(1) In M series, or in T series when JRV, bit 4 of parameter No.1402, is set
to 0 (feed per minute), specify a jog feedrate at feed per minute with an
override of 100%.
[Unit of data, valid range]
Increment system
Unit of data
Valid data range
I
ncremen
t
sys
t
em
U
n
it
o
fd
a
t
a
IS-B IS-C
Millimeter machine 1 mm/min
Inch machine 0.1 inch/min
6 to 32767
Rotaiton axis 1 deg/min
