4. DESCRIPTION OF PARAMETERS
29
#7
BFA
1300
#6
LZR
LZR
#5
RL3
#4 #3 #2
LMS
LMS
#1 #0
OUT
OUTBFA
[Data type] Bit
OUT The area inside or outside of the stored stroke check 2 is set as an
inhibition area. (Setting by parameter 1322 or 1323)
0: Inside
1: Outside
LMS The EXLM signal for switching stored stroke check 1
0: Disabled
1: Enabled
NOTE
Stored stroke check 1 supports two pairs of parameters for
setting the prohibited area. The stored stroke limit switching
signal is used to enable either of the prohibited areas set with
these parameter pairs.
(1) Prohibited area I: Parameters No.1320 and No.1321
(2) Prohibited area II: Parameters No.1326 and No.1327
RL3 Stored stroke check 3 release signal RLSOT3 is
0: Disabled
1: Enabled
LZR Checking of stored stroke check 1 during the time from power–on to the
manual position reference return
0: The stroke check 1 is checked.
1: The stroke check 1 is not checked
NOTE
When an absolute position detector is used and a reference
position is already set upon power–up, stored stroke limit
check 1 is started immediately after power–up, regardless of
the setting.
BFA When a command that exceeds a stored stroke check is issued
0: An alarm is generated after the stroke check is exceeded.
1: An alarm is generated before the stroke check is exceeded.
NOTE
The tool stops at a point up to F/7500 mm short of or ahead
of the boundary.
(F: Feedrate when the tool reaches the boundary (mm/min))
#7
1310
#6 #5 #4 #3 #2 #1
OT3x
#0
OT2x
OT2x
[Data type] Bit axis
OT2x Whether stored stroke check 2 is checked for each axis is set.
0: Stored stroke check 2 is not checked.
1: Stored stroke check 2 is checked.
