Series 0i - Model A Parameter manual Page 41

Parameter manual
B–63510EN/01
4. DESCRIPTION OF PARAMETERS
35
<For T series>
F8A Valid data range for an F command in feed–per–minute mode
0: Range specified with bit 0 (MIF) of parameter No.1403
Increment system Units IS–B IS–C
Millimeter input mm/min 0.001 to 240000. 0.001 to 100000.
Inch input inch/min 0.00001 to 9600. 0.00001 to 4000.
Rotation axis deg/min 1 to 240000. 1 to 100000.
<For M series>
F8A Valid data range for an F command with a decimal point in feed–per
minute mode
Increment system Units IS–B IS–C
Millimeter input mm/min 0.001 to 99999.999.
Inch input inch/min 0.00001 to 999.99999.
Rotation axis (mm) deg/min 1 to 240000. 1 to 100000.
Rotation axis (inch) deg/min 1 to 9600. 1 to 4000.
Increment system Units IS–B IS–C
Millimeter input mm/min 0.001 to 240000. 0.001 to 100000.
Inch input inch/min 0.00001 to 9600. 0.00001 to 4000.
Rotation axis deg/min 1 to 240000. 1 to 100000.
FRV For inch input, the valid range of the feedrate specified for feed per
revolution is:
0 : Standard range. (F0.000001 to 9.999999 inches per revolution)
1 : Extended to F50.0 inches per revolution. (F0.000001 to 50.000000
inches per revolution)
#7
1405
#6 #5 #4 #3 #2 #1
FD3
#0
F1U
[Data type] Bit
F1U Specifies the units of the data for the parameters that set the feedrates of
the F1–digit feed commands (parameter Nos. 1451 to 1459).
Increment system
Units of data
I
ncremen
t
sys
t
em
When F1U is 0 When F1U is 1
Millimeter machine 0.1 mm/min 1 mm/min
Inch machine 0.001 inch/min 0.1 inch/min
Rotation axis 0.1 deg/min 1 deg/min
FD3 The number of significant digits of the fractional part in the feedrate
command (F command) for feed per revolution is:
0 : Up to two decimal positions (three decimal positions for inch input).
1 : Up to three decimal positions (four decimal positions for inch input).
1:
0:
1:
