Series 0i - Model A Parameter manual Page 232

Parameter manual
4. DESCRIPTION OF PARAMETERS
B–63510EN/01
226
#7
8132
#6 #5
SCL
#4
SPK
#3
IXC
#2
BCD
BCD
#1
YOF
#0
TLF
TLF
NOTE
When this parameter is set, the power must be turned off
before operation is continued.
[Data type] Bit
TLF Specifies whether to use tool life management, as follows:
0 : Not to use.
1 : Use.
YOF Specifies whether to use Y–axis offset, as follows:
0 : Not to use.
1 : Use.
BCD Specifies whether to use the 2nd auxiliary function, as follows:
0 : Not to use.
1 : Use.
IXC Specifies whether to use index table indexing, as follows:
0 : Not to use.
1 : Use.
SPK Specifies whether to use small–hole peck drilling cycle, as follows:
0 : Not to use.
1 : Use.
SCL Specifies whether to use scaling, as follows:
0 : Not to use.
1 : Use.
NOTE
Both a peck drilling cycle for a small diameter and scalling
cannot be selected at the same time.
