2. HARDWARE

B–63505EN/02

(1)LED status in power on routine (Green LED)

j:OFF J:ON

STATUS jjjj Power off

STATUS JJJJ State in which software is being loaded to DRAM after

power–on, or when CPU operation is stopped be-

cause of an error

STATUS JjJJ Waiting for other CPU’s answer (ID setting)

STATUS jjJJ Detect other CPU’s answer (Finished of ID setting)

STATUS JJjJ FANUC BUS initialized

STATUS jJjJ PMC initialization finished

STATUS JjjJ All PCBs configuration finished

STATUS JJJj PMC initial running finished

STATUS jJJj Waiting for digital servo initialization

STATUS Jjjj All initialized, running

(2)LED status in power of alarm

j:OFF J:ON

STATUS jJjj

ALARM JJj

RAM parity alarm occured in main CPU board

STATUS jJjj

ALARM jJJ

Servo alarm (watch dog alarm) occured

STATUS jJjj

ALARM jJj

Other system alarm occured

D LED display
