1. DISPLAY AND OPERATION

B–63505EN/02

(4)Data number: The table below lists the numbers of the data items for

which a waveform can be displayed (n = 1 to 4).

Data

No.

Description Units

00 Does not display a waveform. –

0n Servo error (8 ms) for the n–th axis (positional deviation) Pulses

(detection units)

1n Pulse distribution for the n–th axis (move command) Pulses

(input increments)

2n Torque for the n–th axis (actual current) % (relative to maxi-

mum current)

3n Servo error (2 ms) for the n–th axis (positional deviation) Pulses

(detection units)

5n Actual speed for the n–th axis min

–1

6n Command current for the n–th axis % (relative to maxi-

mum current)

7n Thermal simulation data for the n–th axis % (OVC alarm ratio)

90 Composite speed for the first, second, and third axes Pulses

(input increments)

99 On/off state of a machine signal specified with a signal

address

None

10n Actual spindle speed for the n–th axis % (relative to maxi-

mum rotation speed)

11n Load meter for the spindle for the n–th axis % (relative to maxi-

mum output)

161 Difference in position error calculated on the spindle

basis

Pulses

(detection unit)

(5)Data units: Weight of data when 1 is specified. The data units are

automatically specified for each data item and need not be set unless

the units must be changed for some reason.

[Valid data range] 1 to 1000

[Unit] 0.001

(6)Signal address: PMC address and bit number. Set in the same way as

that for trigger, when the data number is 99.
